GT41 Series Heavy Duty Tool Cabinet

Free configuration of slide rails

The drawer slides of the tool cabinet offer multiple extension options and load capacities depending on the tools or equipment stored. Industrial-grade tool cabinets can be flexibly configured with two different functions to meet diverse needs.

Single slide drawer：Supports up to 100 kg with 85% smooth extension, ideal for standard industrial storage.

Double slide drawer：Double-slide design supports 150 kg with 100% full extension, perfect for heavy-duty storage and access.

Optimum order and organisation

Dividers, partition boxes, and separator slots help maximize the internal space of each drawer in the tool cabinet. By using these accessories, work efficiency and speed are significantly improved, allowing each drawer to neatly store a specific set of tools, spare parts, and small components.

Drawer divider：Pre-formed divider holes are reserved in the drawer, and optional front-to-back adjustable dividers can be configured. Supports 3×3, 3×4, 3×5, and other customized partition layouts.

Divider box：Made of one-piece molded ABS material. Classification boxes can be selected according to usage needs and part sizes, enhancing the convenience of tool management.

Outstanding safety features

Depending on different scenarios and security requirements, the tool cabinet can be equipped with three types of locking systems to prevent loss and ensure safe and reliable storage and use.

Centralized lock：Equipped with a central locking system, all drawers can be locked or unlocked with a single lock. Each lock comes with two keys.

Self-locking system：Equipped with self-locking buckle design, effectively preventing drawers from sliding off accidentally.

Interlocking system(optional)：Ensures that only one drawer can be opened at a time, thus preventing tipping and enhancing stability, providing additional security.

Sturdy and durable

A workbench can be installed on top of the tool cabinet to enhance strength and durability, providing support for repairs and other tasks. Tool cabinets with drawers can also be flexibly equipped with four different types of work surfaces to meet diverse usage needs.

GT41 Series Heavy Duty Tool Cabinet

ART.	Size	Drawer Qty	Slide	Drawer		N.W./G.W.	CBM(m³）
GT41577003E	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	3	Single Slide	100KG	85%	44.8KG/49KG	0.2
GT41577003V	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	3	Double Slide	150KG	100%	54.8KG/59KG	0.2
GT41577004E	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	4	Single Slide	100KG	85%	50.8KG/55KG	0.2
GT41577004V	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	4	Double Slide	150KG	100%	62.8KG/67KG	0.2
GT41577005E	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	5	Single Slide	100KG	85%	55.8KG/60KG	0.2
GT41577005V	W16.2″ * D22.5″ * H27.6″ W412*D572*H700mm	5	Double Slide	150KG	100%	70.8KG/75KG	0.2

All Figures In mm
